Tomy SX-700E - Control Panel and Indicators

ー11ー
Control panel display
①
②
③
④
⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪
⑫ ⑬ ⑭ ⑮ ⑯ ⑰
Inside of the chamber
Temperature sensor
Detecting the temperature in the chamber.
Drain hole
Drains sterilizing water from the chamber.
Leads to the drain port.
Heating Element (Heater)
Heating sterilizing water.
Water level sensor
Detecting the level of sterilizing water at
the bottom of the chamber.
●
●
●
●
