Manual TT-188 - 22 -
14. Spare parts and pump spares
14.1 Spare parts
Mechanical components:
Bb0300000 Screw fastener for case (bayonet screwing and cage)
Bb0300001 Insert for screw fastener for fixing in case
Bb0300100 Door locking für door electro cabinet
Ca2000500 Screwed cap for manual refill pipe 1“
De0300200 Drain angle 90° for tank drainage
Db0500200 Seal for tank cover silicone profile, length 900 mm
Dc0100000 Steering rollers Ø 50 mm with central fixing
De0100400 Water filter R 3/8“, for cooling water in, with mesh bottom
Df0200000 Solenoid valve R 3/8“, for water cooling
Df0200100 Solenoid valve R 1/4", for refill
Df0200600 Trip coil 230 V, 50/60 Hz. adapted to all solenoid valves, Ø 12 mm
Df0200900 Repair kit for solenoid valve R 1/4", plug and spring
Df0200901 Repair kit for solenoid valve R 3/8“, membrane, spring, plug
Gm0100800 Heating 3000 W 3 x 380 – 420 V / 59 Ohm, isolator blue, incl. seal and clip
Db0200500 Seal for heating 3000 W, Ø 20 mm
Gm0101100 Heating connecting clip 2 pieces, with cable and shrinkdown plastic tubing
Gf0101200 Capillary pipe thermostat +80-370°C
De0701600 Pressure gauge Ø 40 mm -1 bis +6 bar, filled with glycerine
De0701201 Fixing clips for pressure gauge 70 x 35 x 2 mm (with straining screw)
Wc0100000 Heat exchanger Modell TT-180
Wd0100000 Float complete with rod and 4 set collars
Wf0100000 Insulation-Set
