Tool-Temp TT-180 User Manual

Manual TT-180 - 2 -
1. Description
The temperature control unit TT-180 is constructed for water operation up to maximum +90°C,
respectively oil operation up to maximum +150°C. For permanent use over +130°C you should use
an other model.
The unit corresponds to the harmonized EU norms as EN 292 / EN 60204 as well as to the relevant
EU directives (see EU conformity declaration) and it is provided with the CE sign.
The TT-180 can be switched from 9 kW for water operation to 3 kW for operation with heat transfer oil.
(see chapter 6.5 and instructions in chapter 15).
serial equipment:
- self-optimizing temperature controller with digital display of the set and actual temperature. Display
in
1
/
10
-° range. Switchable from °C to °F.
- automatic temperature monitoring. Deviation between effective and set temperature activates an alarm.
- switchable from 3 kW oil operation to 9 kW water operation
- heating switchable in stages at 9 kW water operation
- lime-free heat exchanger
- horn for fault messages
- automatic level control to prevent the unit from running dry
- mechanical safety thermostat and electronic temperature limiter installed in the controller
- autom. water refill or manual oil refill
- with main switch, automatic cutout, transformer and motor protection switch
- with castors
2. Technical data
Temperature range Up to +90°C with water / up to +150°C with oil
Temperature control self optimizing microprocessor controller MP-888
heating power
water operation: 9 kW, switchable in stages 3/6/9 kW
oil operation: 3 kW
pump capacity
connected load 0,75 kW
pressure mode max. 4,5 bar / max. 75 l/min.
suction mode - vacuum max. 8 mWS
cooling power approx. 18 kW at +90°C
filling amount approx. 6 litres
Connections
heating medium R 1/2“ female thread
cooling water R 3/8“ male thread
dimensions in mm
(incl. castors)
Length: 670
Width: 260
Height: 650
Weight empty ca. 55 kg
category of protection IP-44
Electric In separate switch cabinet, easily accessible from the front
Colour silver grey RAL 7001
heat exchanger low-maintenance
noise level (dBA) < 70 (distance 3 m)
