8
Names of parts
Names of parts
Names of parts on the main body
Top cover
Sensor
Lamp cover
Front panel
Barrel screw
Base
Power switch
RS232C connector
Power socket
Fuse holder
Voltage selector
Power plug
(only MC type)
(Some types do not have i
t
in the standard kit.)
