9
CF card eject button
To eject the CF card, stand the button up,
then press it.
Card slot side
CF slot
SD slotHard reset switch
USB Connector
(Type Mini-B)
Serial Connector
Connector side
These figures show the FC-200 with the cap opened.
USB Connector
(Type A)
