Topcon FC-200 - Using Wireless LAN (Option); Using Radio System RS-1 (Option)

23
Using Wireless LAN (Option)
It is possible to connect to a network via wireless if Wireless LAN function, an optional hardware, is
used.
Wireless LAN ON/OFF
Follow the procedure below to turn on the Wireless LAN function.
1 Tap on [Start][Settings][Control Panel][WLan Power] icon.
2 On the [Wireless LAN Power] screen, tap on the [POWER ON] button.
When the Wireless LAN function is turned ON, the wireless LED will flash in red color.
Using Radio System RS-1 (Option)
Installing the Radio System RS-1, an optional system, enables transmission with Total Station with
wireless.
Refer to the application help for details on setting RS-1.
Turn on Wireless LAN only when being used. If Wireless LAN is left ON, operation time will be shortened.
Turn on RS-1 only when being used. If RS-1 is left ON, operation time will be shortened.
