Operating time *5) : Approx. 15 hours (Standard capacity)
Suspend (Power OFF) holding time
: Approx. 4 days (when fully charged batteries are used)
Charging time : Approx. 4 hours (with AC-DC converter AD11B/11C)
Dimensions : 196×107×61 (mm)
Weight : 0.72kg (with battery)
*1) Connector size is within 9.0×16.5 mm.
*2) Transmission distance is influenced by the environment. The distance of radio wave transmission may be reduced in
reinforced concrete buildings or near large-sized metal furniture.
*3) When caps are installed.
*4) Each of the instrument's 6 sides was dropped onto a concrete surface, and the instrument's operation was then
confirmed. Only the exterior of the instrument was damaged.
*5) Battery capacity will differ depending on whether Bluetooth is used or not, brightness of the backlight, room temperature
and application software used.
(When Bluetooth is used, battery capacity will lower approximately 30%)
Battery (BT-66Q)
Type : Lithium-ion battery
Regular voltage : 7.4V
Nominal capacity : 2,500mAh
Exterior dimensions : 72×39×22 (mm)
Weight : 110g
AC-DC Converter (AD-11B/11C)
Input : 100~240V 50~60Hz, 1.4A
Output : 12V 3A Max. 36W
Charging temperature : 0°C to +40°C
Exterior dimensions : 88×41×27 (mm)
(Not including cable)
Weight : 200 g
