GC-35 Setup
Profiler (Milling) Applications
13
P/N: 1001548-01
b. If the slope displayed in the box does not match the surface, then you must calibrate the slope sensor.
8. Press and hold the Menu/Set button, then turn the Grade Adjustment Knob to change the display’s slope
percentage to match the slope of the surface.
9. Press the Auto button to switch to Auto, and begin milling.
10. Use the Grade Adjustment Knob as needed to make changes to the slope value.
Once the slope sensor is calibrated and you are ready to begin milling, you may find the existing surface does not
have the same slope as the finish design. In order to produce a smooth transition, begin milling at the existing
slope and slowly turn the Grade Adjustment Knob to change the cross slope to the correct percentage.
GC-35_QRG.book Page 13 Tuesday, January 31, 2017 3:43 PM
