1 NOMENCLATURE AND FUNCTIONS
1-9
1 儀器諸元及功能說明
1.1 儀器諸元
提把式電池 BT-30Q
Lower horizontal clamp
底座
外接電源端子
顯示幕
操作按鍵
目鏡
點位導引器
(Point guide type only)
保險絲鎖蓋(4A)
電池鎖扣
儀器中心點
覘標
序列訊號端子
光學求心器
踵定螺旋
