11
4. NOMENCLATURE AND FUNCTIONS
Displaying battery life
The battery life is low when the power LED is blinking in red and a beep sound (repeating beeps) is
heard. Exchange the battery. The battery life of the instrument is displayed on the controller.
Refer to the instruction manual of the controller.
Laser plummet ON/OFF and brightness adjustment
The operation method of the laser plummet is as follows:
W-LAN LED When it is Mode A
Connection waiting state: Blinking in green every 1 second
(repeating a cycle in which the LED
is on for 1 second and then off for
1 second)
Connecting: Lighting up in green
When it is Mode B
Connection waiting state: Blinking in green quickly
(repeating a cycle of quick on twice,
followed by 2 seconds off)
Connecting: Lighting up in green
When an error is detected in the W-LAN setting item:
Lighting up in red
Laser plummet switch Laser plummet ON: Press it
Laser plummet OFF: Press and hold (More than 1 second).
“Laser plummet ON/OFF and brightness adjustment” on
page 11
Laser plummet/
Laser pointer LED
Off: Laser plummet or laser pointer is OFF
Blinking in green: Laser plummet or laser pointer ON
Auto leveling switch Starts auto leveling: Press it while auto leveling is stopped.
Stops auto leveling: Press it again while auto leveling is being
performed.
Extends the leveling screw:
Hold it down.
“Auto leveling” on page 18
Auto leveling LED Blinking in green: In auto leveling
Lighting up in green: Within the range of inclination
compensation (±6 minutes)
Lighting up in red: Outside the range of inclination
compensation (±6 minutes or over)
Blinking in red: Outside the range of auto leveling
Function Description
Turn ON the laser plummet Press the {laser plummet switch} for a short time.
The laser plummet lights up with the stored brightness.
Turn OFF the laser plummet Hold down the {laser plummet switch} for at least 1 second or it
turns OFF automatically about five minutes after the laser
plummet is turned ON. The brightness used when the laser
plummet turned OFF is stored.
Turn up the brightness Pressing the {laser plummet switch} for a short time while the
laser plummet is turned ON turns up the brightness by one level,
up to level 5. After reaching level 5, it goes back to level 1.
To Next Page
