Topcon LN-100 - W-LAN Connection Methods

15
5. PREPARATION
There are two methods to set up a W-LAN connection between the instrument and the controller:
 Mode A connection
This is a one-to-one connection using the instrument as a master machine and the controller as a
slave machine for W-LAN connection. When using the Mode A connection, the instrument performs
as a DHCP server.
For details of the connection method, refer to the instruction manual of W-LAN Config for LN-100.
 Mode B connection
Connect via other access point (as the master machine) using the instrument and the controller as
slave machines for W-LAN connection.
For details of the connection method, refer to the instruction manual of W-LAN Config for LN-100.

• The network settings of Mode A and Mode B are saved one each.
5.2 W-LAN Connection with the Controller
Master machine
Slave machine
Master machine
Slave
machine
