TRL-35 Configuration
TRL-35 Operator’s Manual
2-14
Simplex protocol, the TRL-35 currently supports
operation as a Transmitter, Receiver, or Repeater.
•Link Rate
The default link rate for DBPSK is 9600 and is recommended
for most applications. The link rate is the rate at which data is
transmitted over the RF Link.
• Output power
Select the level of power for RF transmissions ranging
from 500 mW to 32W (45 dBm).
9. Click on the Serial Interface tab (Figure 2-15).
Figure 2-15. Serial Interface Screen
10. On the Serial Interface screen, select a baud rate for the modem’s
serial port. The same rate must be used for both the receiver and
the transmitter. The recommended baud rate is 38400.
11. On the Serial Interface screen, select the RTS/CTS (Ready to
Send/Command to Send) to be ON.
Table 2-2. Modulation Type for Link Rate
For Link Rate Use Modulation Type
4800 baud DBPSK
9600 baud (default; recommended) DBPSK (recommended) or DQPSK
19200 baud DQPSK
