Topens A3 - Technical Specifications

6
Replacement Parts
EKPKMJ2B Control
Board for A3/ A3S Gate
Opener
EKPKMJ1B Control
Board for A5/ A5S/ A8/
A8S Gate Opener
ALS01 Limit Switch
A3JB/ A5JB/ A8JB Arm
Actuator
TS24-U Adapter
MK01 Hardware Kit
Tools Needed:
·Power Drill
·Tape Measure
·Open End Wrenches - 14# &17# or Adjustable Wrenches
·Wire Strippers
·C-Clamps - small, medium, and large
·Level
·Hacksaw or Heavy Duty Bolt Cutters
·Phillips Screwdriver
Technical Specifications & Features
Specifications
A3(S)
A5(S)
A8(S)
Input:
Adapter Input: 100-240V~ 50/60Hz
Motor voltage:
24VDC
Power:
30W
50W
80W
Current:
1.5A
2A
3A
Actuator speed:
16mm/s（0.6 in/s）
Max. actuator travel:
385mm（15.2 in）
Ambient Temperature:
-20℃~ +50℃ (-4°F to 122°F)
Protection class:
IP44
WARNING: Changes or modifications not expressly specified by this user manual, TOPENS could void
the warranty of this equipment.
