18
12. Open the release hole plug on the top of the gate opener, insert the release key, and turn the key 90°
counterclockwise. This restores normal operation.
NOTE: The setting of the PULL/PUSH TO OPEN of the control board should be in accordance with the
installation.
Mounting of the Control Box
Use 2 deck screws (not provided) to install the control box. Even though the control box is waterproof designed,
for safety reason and a longer service life, it is recommended to install the control box inside a secure surface
and at least 100 cm (40 inches) above the ground to avoid being flooded or buried under snow.
CAUTION: Make sure the cable outlet hole in the Control Box is always down during installation so as to drain
off the water.
Connection of the Power Supply
The gate opener can be powered by 24V 12Ah battery (NOT INCLUDED) OR DPS180-U AC-DC
Power Supply (NOT INCLUDED, available at TOPENS Store). The adapter included in the package is
ONLY used to charge the battery.
Instead of using a battery, the AC-DC Power Supply is highly recommended as the power source to
save the cost where AC electricity is accessible and stable.
If batteries are chosen as the power source, Marine or Automotive Type Battery with capacity
