Toppro TPR-5000 - Connecting the Digital Receiver

10 Setup
.
.
.
4
AUDIO L/R Stereo audio output socket for the televi-
sion set or the audio-video receiver (white/red)
.
.
.
5
Y/Pb/Pr Component video output socket for the tele-
vision set
(green/blue/red)
.
.
.
6
S/PDIF Digital audio output socket for the audio-
video receiver
.
.
.
7
HDMI Audio and video output socket for the high
definition television set
.
.
.
8
LAN Local area network port
.
.
.
9
USB USB port for firmware update and data trans-
fer
Table 2.3: Connectors specifications
HDMI High definition video output
Left & right audio output
Digital audio output
YPbPr Component video output
VIDEO Composite video (CVBS) output
AUDIO Left & right audio output
S/PDIF Digital audio output
LAN 10/100 Ethernet
USB 2.0 Host (5 V DC, 500 mA)
2.4 Connecting up your digital receiver
There are several ways to set up the digital receiver. Set up the
digital receiver suitably to your television and other devices.
If you have any problem with your setup or need help, contact
your dealer.
