Topshine MT01 - 4 Specifications

Guangzhou Topshine Information Technic Co., LTD
Address: RM 605, #52 SHUI YIN RD, YUE XIU DIST, GUANGZHOU, CHINA
User manual of tracker MT01
-
5
-
* Built-in motion sensor for power & GPRS flow saving mode (sleep mode)
* I/O: 3 Inputs, 1 Output ,1 AD
* Over speed alert
* Geo-fence alert
* Power failure/low power alert
* SOS Panic button, SOS alert
* Accident alarm (need crash sensor support) (optional)
* Wiretapping/remote listening (optional)
4. Specifications
Items
Specifications
Dimension
80*58*22mm
Weight
90g
Input voltage
DC 9V~36V/1.5A
Back-up Battery
650mAh/3.7V
Power Consumption
65mA standby current
Operating Temperature
-40°C~75°C
Humidity
5%~95%
Work Time
33 hours in power-saving mode and 8 hours in normal mode
LED
2 LED lights to show GPS, GSM status
Button
1 SOS and 1 power on/off
Microphone
optional
Sensor
Motion sensor
GSM Frequency
GSM 850/900/1800/1900MHz
GPS Chip
Ublox7
GPS Sensitivity
-160dBm
Positioning Accuracy
5meter，CEP
I/O
3 Inputs , 1 Outputs , 1 AD
