TORAIZ SQUID - Rear Panel Layout; Rear Panel Terminals

8
En
Rear Panel
1 Cable hook
2 DC IN terminal
3 u button
Turns the power of this unit On/Off.
w On/v Off
This switch is between off and on for this unit.
4 USB-B terminal
5 MIDI THRU/OUT2 terminal
6 MIDI OUT1 terminal
7 MIDI IN terminal
8 CV OUT1 terminal
9 GATE OUT1 terminal
a CV OUT2 terminal
b GATE OUT2 terminal
c CLOCK OUT terminal
d CLOCK IN terminal
e DIN SYNC OUT1 terminal
f DIN SYNC IN/OUT2 terminal
g Kensington lock slot
