TorcUP AP1000 - MANIFOLD ASSEMBLY; PART# 46292 SS MANIFOLD ASM.; PART# 68999 SS INT. RELIEF ASM.

MANIFOLD ASSEMBLY
ITEM # DESCRIPTION PART # QTY.
01 VALVE MANIFOLD 46270 1.00
02 CARTRIDGE RELIEF VALVE 45423 1.00
03 1/16 PIPE PLUG-FLUSH 40049 3.00
04 PIPE PLUG 1/8" FLUSH 81093 3.00
05 PIPE NIPPLE 1/8 NPT 68917 1.00
06 PIPE COUPLING 1/8 68918 1.00
07 INT.RELIEF ASM HF
68999SS 1.00
(68999SS) INT. RELIEF ASM.
ITEM # DESCRIPTION PART # QTY.
01 CARTRIDGE 66096 1.00
02 CONE REL VLVE 66086 1.00
03 POPPET RELIEF SPRING 44641 1.00
04 RELIEF VALVE ADJUSTING SCREW 66083 1.00
05 HEX NUT 7/16-20 68920 1.00
PART# 46292SS MANIFOLD ASM.
PART# 68999SS INT. RELIEF ASM.
