Torex VDC Series - VDC 315

3 - Spare Parts Catalogue
5
TO320 R - EN - Ed. 04.09
Pos. Quantity Description Code
1 2 Body
2 2 High temp. gasket
3 2 Hopper See Table 1
4 4 M10x30 ISO10462 TPSEI Screw
5 4 Ø10 DIN 7980 Washer
6 4 M10 ISO 4032 Nut
7 2 Shaft
8 8 Packing gland
9 4 Stufng box
10 16 M10x45 ISO 4017 HH Screw
11 4 Spring retainer plate
12 4 “UCF 206” type support
13 4 Compression spring
14 16 Ø10x30 UNI 6593 Disk washer
15 16 Ø10 ISO 7089 Flat washer
16 16 Ø10 DIN 7980 Split washer
17 16 M10 ISO 4032 Nut
18 2 High temp. gasket
19 2 Rear cover
20 8 Ø10 ISO 7089 Flat washer
21 8 Ø10 DIN 7980 Split washer
22 8 M10x30 ISO 4017 HH Screw
23 2 Flap See Table 2
24 2 Lever for ap
25 2 Pin
26 4 Ø4x35 ISO 1234 Split pin
27 2 M10x12 ISO 4027 ECEI Grub screw
28 12 M10x50 ISO 4017 HH Screw
29 24 Ø10 ISO 7089 Flat washer
30 12 Ø10 DIN 7980 Split washer
31 12 M10 ISO 4032 Nut
32 4 ISO 773 8x7x40 Key
VDC 3151.3
