Torex VDC Series - VDC 200

20 3 - Spare Parts Catalogue
TO320 R - EN - Ed. 04.09
VDC 2004.1
Pos. Quantity Description Code
1 2 Lever for shaft
2 2 M10x12 ISO 4027 ECEI Grub screw
3 2 M12 autoblock nut DIN 985
4 2 Pin for cylinder
5 2 Swivel joint
6 2 Seeger ring Ø10 DIN 471
7 2 Ø25 cylinder 100 mm stroke ISO 6432
8 4 Sensor for cylinder
9 4 1/8" ow regulator Ø8 tube
10 4 M6 ISO 4032 Nut
11 4 Ø6 DIN 7980 Split washer
12 2 Cylinder rear hinge
13 4 M6x16 ISO 4017 HH Screw
14 4 M8x16 ISO 4017 HH Screw
15 2 Cylinder rear support
16 1 Reducer plate
17 4 Stud bolt
18 8 Ø12x36 UNI 6593 Disk washer
19 8 Ø12 DIN 7980 Split washer
20 8 M12x40 ISO 4017 HH Screw
21 16 Ø6x18 UNI 6593 Disk washer
22 16 Ø6 DIN 7980 Split washer
23 16 M6x20 ISO 4017 HH Screw
24 1 Guard
25 1 Pneumatic control unit VMX10
26 Ø8 Tube
27 4 M6x16 ISO 4017 HH Screw
28 4 Ø6 ISO 7089 Flat washer
29 1 Junction box
30 1 Junction box support
31 4 Ø6x18 UNI 6593 Disk washer
32 4 Ø6 DIN 7980 Split washer
33 4 M6 ISO 4032 Nut
