Torex VDC Series - VDC 200

3 - Spare Parts Catalogue
13
TO320 R - EN - Ed. 04.09
VDC 2003.1
Pos. Quantity Description Code
1 2 Lever for shaft
2 2 Spacer
3 2 12x34x14 bearing (type 62201 2RS)
4 2 M12 autoblock nut DIN 985
5 4 Spacer for bearing (SKF ZW 12x17 th.2)
6 4 Ø12.5x48 UNI 6593 Disk washer
7 1 Spring 20953611B
8 2 Ø12 ISO 7089 Flat washer
9 2 M12x70 ISO 4017 HH Screw
10 2 M10x12 ISO 4027 ECEI Grub screw
11 1 Pin for bearing
12 1 20x42x12 bearing (type 6004 2RS)
13 1 Washer for bearing
14 1 Reduction gear crank
15 2 ISO 773 8x7x40 Key
16 8 M12x40 ISO 4017 HH Screw
17 8 Ø12 DIN 7980 Split washer
18 8 Ø12x36 UNI 6593 Disk washer
19 4 Stud bolt
20 1 Reducer plate
21 4 M10 ISO 4032 Nut
22 4 Ø10 DIN 7980 Split washer
23 8 Ø10 ISO 7089 Flat washer
24 1 Reduction gear 7202ST0400
25 1 Motor MV0710B04145
26 4 M10x40 ISO 4017 HH Screw
27 1 Ø12x36 UNI 6593 Disk washer
28 1 Ø10 DIN 7980 Split washer
29 1 M10x30 ISO 4017 HH Screw
30 1 Guard
31 14 Ø6x18 UNI 6593 Disk washer
32 14 Ø6 DIN 7980 Split washer
33 14 M6x20 ISO 4017 HH Screw
