Torex VDC Series - VDC 400

6 3 - Spare Parts Catalogue
TO320 R - EN - Ed. 04.09
Pos. Quantity Description Code
1 2 Body
2 2 High temp. gasket
3 2 Hopper See Table 1
4 4 M10x30 ISO10462 TPSEI Screw
5 4 Ø10 DIN 7980 Split washer
6 4 M10 ISO 4032 Nut
7 2 Shaft
8 8 Packing gland
9 4 Stufng box
10 16 M12x60 ISO 4017 HH Screw
11 4 Spring retainer plate
12 4 “UCF 208” type support
13 4 Compression spring
14 16 Ø12x36 UNI 6593 Disk washer
15 16 Ø12 ISO 7089 Flat washer
16 16 Ø12 DIN 7980 Split washer
17 16 M12 ISO 4032 Nut
18 2 High temp. gasket
19 2 Rear cover
20 8 Ø10 ISO 7089 Flat washer
21 8 Ø10 DIN 7980 Split washer
22 8 M10x30 ISO 4017 HH Screw
23 2 Flap See Table 2
24 2 Lever for ap
25 2 Pin
26 4 Ø4x35 ISO 1234 Split pin
27 2 M10x12 ISO 4027 ECEI Grub screw
28 20 M12x60 ISO 4017 HH Screw
29 40 Ø12 ISO 7089 Flat washer
30 20 Ø12 DIN 7980 Split washer
31 20 M12 ISO 4032 Nut
32 4 12x8x70 ISO 773 Key
VDC 4001.4
