GENERAL LAYOUT2.
General layout of VDC with counterweight2.1
In VDC with counterweight, the opening of the plate depends on the weight of the material.
The force of the material on the plate must overcome the force exerted by the weight on the lever.
The working is not regular over time.
General layout of VDC with counterweight
Pos. Qty. Description
1 2 Body
2 2 Shaft
3 2 Flap
4 2 Cover
5 4 Bearing
6 2
Lever for counterweight
7 2 Counterweight
8 2 Hopper
1
2
4
5
3
6
7
8
