Torex VDC Series - VDC 500

3 - Spare Parts Catalogue
29
TO320 R - EN - Ed. 04.09
Pos. Quantity Description Code
1 2 Sensor unit guard
2 4 Ø5 DIN 7980 Split washer
3 4 M5x10 ISO 4017 HH Screw
4 2 M8x16 ISO 4017 HH Screw
5 2 Ø8 DIN 7980 Split washer
6 2 Blade
7 2 M12x40 ISO 4017 HH Screw
8 4 Ø12 DIN 7980 Split washer
9 2 Ø12x36 UNI 6593 Disk washer
10 2 Rotation sensor connection
11 2 Rotation sensor 3860IF0050
12 2 M8 ISO 4032 Nut
13 2 Ø8x24 UNI 6593 Disk washer
14 2 Sensor protection
15 2 M8x25 ISO 4017 HH Screw
16 2 VDC body
17 4 M12 ISO 4032 Nut
18 2 Shaft
VDC 5005.5
