10 Instructions for Use TORMAX iMotion 1301/1301.S / 1302.KI /1401 T-1305 en
1 Drive
a) Motor unit
b) MCU32 control system with monitoring system, power limitation and
permanent diagnosis.
£ Controlled closing function of the door in power-o condition
£ Controlled opening function in power-o condition
c) Linkage / sliding lever (1301, 1301.S)
d) £ Pull arm (1401)
e) £ Panic fitting (not approved for drive type 1302.KI-UL)
2 Drive accessories
a) £ Emergency power supply via the battery unit
£ Mechanical door coordinator for double-leaf doors
£ …
3 Door leaves
a) Swing leaf with main closing edge (ME) and secondary closing edge (SE) *
b) £ Finger protection, safeguarding the secondary closing edge *
4 Operating controls
a) £ iMotion user interface with 6 operating modes and fault display
b) £ Operating mode switch with 3 positions
c) £ Lock for the user interface
d) £ Remote control of operating modes
5 Internal activators
a) With automatic activation b) With manual activation
£ Radar with/without direction recognition
* £ Push button *
£ IR motion detector * £ Contact-free button *
£ Contact mat * £ …
6 External activators
a) With automatic activation b) With manual activation
£ Radar with/without direction recognition * £ Key switch
£ IR motion detector * £ Card reader *
£ Contact mat * £ Remote control *
£ … £ …
7 Safety sensors
a) £ Presence sensor * safeguarding the swing area when closing
b) £ Presence sensor * safeguarding the swing area when opening
c) £ Presence
sensor * safeguarding the opposing closing edge (OE)
d) £ Presence sensor * safeguarding secondary closing edge (SE)
£ …
8 Emergency systems
a) £ Power switch / fuse * b) £ Emergency-o switch *
c) £ External fire alarm system *
9 Output message
£ Bell / gong * £ Light * £ Door status
10 Lock
a) £ Electrical door opener *
b) £ Door handle
*
c) £ Mechanical door lock
*
£ Depending on the system’s equipment
* Provided by the installation company.
The company installing the system must select and install suitable components in accordance with the prod-
uct standard EN16005 .
