11
PARTS LIST
JUMBO COVER ASSY. (95000)
ITEM QTY. PART NO. DESCRIPTION ITEM QTY PART NO. DESCRIPTION
1 1 14395
TANK COVER PLUG ASSY.
13 2 02038
SCREW-PHIL. RND HD MACH
2 2 08004
GASKET
14 2 01574
WASHER- LOCK
3 2 14415
ADAPTER
15 2 01497
NUT-FINISHED HEX
4 8 17792
SCREW-TCT (F) PAN HEAD
16 1 04908
GASKET, FLANGE
6 2 11386
GASKET
17 10 00851
WASHER- PLAIN 1/4"
7 8 11394
SCREW-PHIL. FLAT HD TAPT
18 10 00086
SCREW-PHIL. RND HD MACH
8 1 13832
TANK COVER
19 2 04997
STAND
9 1 08057
THUMB SCREW-JUMBO TOOL
20 2 11358
GUIDE-INTAKE
10 1 07648
NAMEPLATE
21 2 12300
PLATE
11 1 17131
GASKET-TANK COVER
22 6 11390
SCREW- T.C.T. PAN HEAD
12 1 90442
DEFLECTOR
CONNECTING HOSE TO INTAKE:
Unscrew or lift locking pin in intake, insert swivel
sleeve as far as possible and then rescrew or release
locking pin. Sleeve will swivel freely when properly
connected.
