12
PARTS LIST
EXTERNAL VAC LIQUID SHUTOFF (90573)
ITEM QTY. PART NO. DESCRIPTION
1 1 14731 TOP PLATE & TUBE S/A
2 4 14732 SPACER
3 4 14733 SCREW-HEX HD CAP
4 1 02247 GASKET
5 1 14735 BOTTOM PLATE
6 1 15517 FLOAT-BALL
7 4 07533 NUT-HEX. LOCK
8 1 15614 SUDS PAN
NOTE:
FOR LIQUID PICK-UP OPERATION:
All Tornado Vacuum Cleaners covered by
this manual are constructed for picking up
water or other solutions without any
adjustments. Liquid shutoffs are available
90573 or 90569.
