PARTS LIST PARTS LIST
INTERNAL FILTER AIR VAC (95990) CONNECTOR ASSY. SINGLE HEAD (95991)
ITEM QTY. PART NO. DESCRIPTION ITEM QTY. PART NO. DESCRIPTION
1 2 01979 SCREW 1 1 06384 JOINT- UNION
2 1 04928 MUFFLER COVER 2 2 05730 PIPE-NIPPLE
3 1 15967 MUFFLER SHELL 3 1 04985 VALVE
4 1 95054 SILENCER 5 1 05731 PIPE -TEE
5 1 05723 NOZZLE 6 1 05733 PIPE-BUSHING
6 2 02038 SCREW 7 1 05732 AIR PRESSURE GAUGE
7 2 01574 LOCKWASHER
8 1 04927 MUFFLER BASE
9 1 05724 GASKET
10 3 02481 "O" RING
13 1 11407 BASE
14 1 05730 NIPPLE
15 1 04982 JET (3/16 DIA.)
1 04983 JET (7/32 DIA,)
1 04984 JET (1/4 DIA.)
16 1 16511 WARNING LABEL
17 1 03008 FILTER
