Tornado 90569

8
PARTS LIST
1-1/2 HP BLOWER MOTORS (98800 / 98801)
PARTS LIST
2-1/4 HP BLOWER MOTORS (98900)
ITEM PART NO. QTY. DESCRIPTION ITEM PART NO. QTY. DESCRIPTION
1 7533 4 Nut-Hex 1 7533 4 Nut-Hex
2 7858 1 Spring-Finger 2 7858 1 Spring-Finger
3 8516 1 Switch 3 8516 1 Switch
4 11276 4 Screw 4 11197 4 Screw
5 11268 1 Cooling Fan Baffle 5 11198 1 Cooling Fan Baffle
6 11269 1 Pad, Fiberglass 6 11199 1 Pad, Fiberglass
7 12436 1 Cover Top 7 12436 1 Cover Top
8 11236 2 Bearing 8 11236 2 Bearing
9 11274 1 Pan Chamber Plate 9 11237 1 Fan Chamber Plate
10 12604 1 Cover Plate 10 12644 1 Cover Plate
11 11275 2 Screw-Hex 11 11239 2 Screw-Hex
12 11240 4 Screw-Phil 12 11240 4 Screw-Phil
13 11241 1 Cable (115V) 13 11241 1 Cable (115V)
19944 1 Cable (230V) 14 11242 1 Fan Spinner
14 11242 1 Fan Spinner 15 11243 1 Motor Housing ASM
15 11243 1 Motor Housing ASM 16 12692 1 Fan
16 12605 1 Fan 17 12642 1 Fan Chamber
17 12641 1 Fan Chamber 18 11252 1 Strain Relief Bushing
18 11252 1 Strain Relief Bushing 19 11253 1 Bumper
19 11253 1 Bumper 20 14322 1 Washer
20 14322 1 Washer 21 11900 1 Nameplate
21 11900 1 Nameplate 23 11278 1 Brush Card Holder A/S
23 11278 1 Brush Card Holder A/S (115V) 24 7534 3 Screw-Phil
24 7534 3 Screw-Phil 25 1713 1 Washer
25 1713 1 Washer 26 10892 2 Nut-Hex. Lock
26 10892 2 Nut-Hex. Lock 27 8220 1 Plug (115V)
27 8220 1 Plug (115V) 28 11255 1 Armature Blower 115V
2563 1 Plug (230V) 29 11256 1 Field Blower 115V
28 11270 1 Armature Blower 115V 30 11249 2 Spring-Spiral Brush
11272 1 Armature Blower 230V 31 11251 2 Carbon Brush 115V
29 11271 1 Field Blower 115V 32 11245 2 Screw
11273 1 Field Blower 230V 33 11244 4 Screw
30 11249 2 Spring-Spiral Brush 34 940 1 Nut
31 11486 2 Carbon Brush 115V 35 5773 1 Nut
11780 2 Carbon Brush 230V 36 11570 2 Brushspg & Damper
32 11245 2 Screw 37 12602 1 Washer
33 11244 4 Screw 38 12603 1 Split Washer
34 940 1 Nut 39 12439 2 Screw
35 5773 1 Nut 40 12601 1 Spacer
36 11570 2 Brushspg & Damper 42 11555 1 Gasket
37 12602 1 Washer 43 11563 1 Gasket
38 12603 1 Split Washer 46 13022 2 Pad-Brush Card
39 12439 2 Screw 47 11250 2 Brush Holder
40 12601 1 Spacer * 14412 1 Label-Warning
42 11555 1 Gasket * 16264 1 Label-Warning
43 11562 1 Gasket * 11415 2 U-Clip
46 13022 2 Pad-Brush Card
47 11250 2 Brush Holder
48 4054 2 Plug-Lock (H/S) #10
49 14624 2 Plug-Hole (Zinc) 1/2 Dia
* 14412 1 Label-Warning
* 16224 1 Label-Warning
* 11415 2 U-clip
