14
PARTS LIST
INTERNAL QUAD AIR VAC (98450)
ITEM QTY. PART NO. DESCRIPTION
1 1 05732 AIR PRESSURE GAGE
2 1 11327 FITTING-GALV. BUSHING
3 4 11323 PIPE-TEE
4 5 11325 FITTING-GALV. ADAPTOR
5 1 11326 VALVE-BALL
6 5 11324 FITTING-IRON ELBOW
7 8 11365 ADAPTOR-MALE
8 2 80592 HOSE-GP BLACK
9 8 05727 CLAMP
10 4 11322 FITTING-GALV. BUSHING
11 2 80592 HOSE-GP BLACK
12 8 01979 SCREW
13 4 04928 MUFFLER COVER
14 4 15967 MUFFLER SHELL
15 4 95054 SILENCER
16 4 05723 NOZZLE
17 8 12812 SCREW
18 8 01589 NUT
19 4 04927 MUFFLER BASE
20 4 05724 GASKET
21 4 04984 JET (1/4)
22 4 02481 RING-O
23 10 02038 SCREW
24 4 32475 PIPE-NIPPLE ½ NPT TAPER
25 4 11317 BASE
26 4 14331 MOUNTING PLATE
27 8 11329 GASKET
28 2 01978 SCREW
29 1 11328 STRAP
30 1 14330 SUPPORT RISER
31 2 01497 NUT
34 2 03144 SPACER
35 1 08057 THUMB SCREW
36 1 14329 QUAD TANK COVER
37 1 17131 GASKET-TANK COVER
38 1 90442 DEFLECTOR
39 1 04908 GASKET, FLANGE
40 4 11331 FLANGE
41 8 05043 RIVET-BLADE
42 4 14407 MOUNTING PLATE
43 4 02706 GASKET
44 4 15517 FLOAT
45 4 06428 CAGE
46 4 06430 TIE WIRE
47 4 02047 SCREW
48 4 07533 NUT
49 2 04997 STAND
50 6 01574 WASHER
51 4 16511 LABEL-WARNING
52 4 03008 FILTER
Recommended air line for Quad Internal operation 1” I.D.
