16
PARTS LIST
EXTERNAL QUAD AIR VAC (98451)
ITEM QTY. PART NO. DESCRIPTION
1 1 05732 AIR PRESSURE GAGE
2 1 11327 FITTING-GALV. BUSHING
3 4 11323 PIPE-TEE
4 5 11325 FITTING-GALV. ADAPTOR
5 1 11326 VALVE-BALL
6 5 11324 FITTING-IRON ELBOW
7 8 11365 ADAPTOR-MALE
8 2 80592 HOSE - GP BLACK
9 8 05727 CLAMP
10 4 11322 FITTING GALV. BUSHING
11 2 80592 HOSE - GP BLACK
12 8 02038 SCREW-PHIL. RND HD MACH
13 20 01574 WASHER-LOCK
14 4 05734 ELBOW CONNECTION
15 2 05735 MUFFLER COVER
16 4 05736 MUFFLER SHELL (AIR VACS)
17 4 05723 NOZZLE
18 8 02038 SCREW
19 8 01589 NUT-FINISHED HEX
20 2 04927 MUFFLER BASE
21 4 05724 GASKET
22 2 04984 JET (1/4)
2 04982 JET .187 ORIF.
2 04983 JET (7/32)
23 4 02481 RING-O
24 8 12812 SCREW-HEX HD CAP
25 4 32475 PIPE-NIPPLE ½ NPT TAPER
26 4 11317 BASE
27 4 14331 MOUNTING PLATE
28 8 11329 GASKET
29 2 01978 SCREW-PHIL. RND HD MACH
30 1 11328 STRAP
31 1 14330 SUPPORT RISER
32 2 01497 NUT-FINISHED HEX
35 2 03144 SPACER
36 1 08057 THUMB SCREW- JUMBO TOOL
37 1 14329 QUAD TANK COVER
38 1 17131 GASKET- TANK COVER
39 1 90442 DEFLECTOR
40 1 04908 GASKET, FLANGE
41 4 11331 FLANGE
42 8 05043 RIVET- BLIND
43 4 14407 MOUNTING PLATE
44 4 02706 GASKET
45 4 15517 FLOAT-BALL
46 4 06428 CAGE
47 4 06430 TIE WIRE
48 4 02047 SCREW-HEX HD MACH
49 4 07533 NUT-HEX. LOCK
50 2 04997 STAND
51 4 16510 LABEL- WARNING
52 2 11576 MUFFLER COVER
53 2 11577 MUFFLER BASE
* 4 05737 GASKET
Recommended air line for Quad Internal operation 1” I.D.
