Tornado 99685 BR 18/11

1
TABLE OF CONTENTS
TECHNICAL DESCRIPTION……….……………………………………..1
WARRANTY ……………………………………………………………….2
SAFETY INSTRUCTIONS………………………………………………....3
FEATURES INSTRUMENT BOARD AND CONTROLS………………...4
FEATURES OF MACHINE………..……………………………………….4
INTRODUCTORY COMMENT……………………………………………4
SYMBOLS…..………………………………………………………. 5
BEFORE USE…………………………………………………………….. 5
Unpacking the machine.....…………………………………… 5
BATTERY INSTALLATION
AND SETTING THE BATTERY TYPE ..........……………………….. 6-7
Battery charger…………..……………..…………………….. 6
Battery disposal…………………………...………………… 6
Battery recharging…………………………...………………. 6
Battery charge level indicator………………...……………… 7
HOUR METER………………………………………………………… 7
SQUEEGEE ASSEMBLY……………………………………………… 7
Adjustment of the squeegee height………………………….. 7
Adjustment of the squeegee inclination…………………….. 7
BRUSH ASSEMBLY………………………………………………...... 7-8
RECOVERY TANK…………………………………………………..... 8
DETERGENT SOLUTION TANK…………………………………….. 8
FLOOR CLEANING…………………………………………………… 8-9
Connecting battery to the machine ……………………. ……... 8
Starting the machine…………....……………………………… 8
Brush pressure adjustment…….……………………………. .. 8
Overflow device….………………………………………………8
Emptying detergent solution…………………………………… .9
Forward movement……………...……………………………... .9
Stop…………………………………………………………….. 9
STOP OF THE MACHINE AFTER CLEANING OPERATION……….9
DAILY MAINTENANCE…………………………………………… 9-10
Recovery tank cleaning……………………………………… 9
Float cleaning……………………………………………….. 9
Brush cleaning………………………………………………. 9
Brush disassembly……………………………………………. 9
Squeegee cleaning…………………………………………….. 10
WEEKLY MAINTENANCE………………………………………….. 10
Rear squeegee rubber replacement…………………………… 10
Squeegee hose cleaning……………………………………… 10
Cleaning of solution tank and filter…………………………… 10
TWO-MONTH MAINTENANCE……………………………………. 10
Front squeegee rubber replacement…………………………… 10
TROUBLESHOOTING GUIDE………………………………………. 11
Signals on the display…………………………………………. 11
The suction motor does not work…………………..…………. 11
The brush motor does not work………………………………. 11
Insufficient water on the brush………………………………… 11
The machine does not clean properly………………………….. 11
The squeegee does not dry perfectly…………………………… 11
Excessive foam production………………………………………11
PROGRAMMED MAINTENANCE……………………………………. 12
TECHNICAL DESCRIPTION
Model BR 18/11
Machine Dimensions
L X W X H 43” X 21” X41”
Net Weight 157lbs.
Solution / Recovery Tank 11 gal. / 12 gal.
Squeegee Width 31”
Design Characters
Tank Construction Polyethylene
Cleaning System
Brush Type Cylindrical
Brush Width 18”
Brush RPM 1300
Brush Pressure 50 lbs.
Cleaning Path 18”
Productivity
Cleaning Rate (Sq. Ft Per Hour) 5000
Motors
Vacuum Motor .6 hp
Brush Motor .6 hp
Sound Level 66 dB
Battery
Voltage 24
