5
SYMBOLS
BEFORE USE
Handling of the packed machine
The machine is supplied with suitable packing
for forklift truck handling.
The total weight is 209 lbs.
Packing dimensions:
Base: 46.26 in. x 26.18 in.
Height: 46.65 in.
ATTENTION:
Do not place more than 2 pallets on top
of each other.
Unpacking the machine
1. Remove the external packing.
2. Unscrew the brackets (1+2) that secure the
machine to the pallet.
3. Move the machine backwards, as indicated
in figure, avoiding heavy contacts to
mechanical parts.
4. Keep the pallet for future transport.
!
