SettingtheHeight/Depthof
theGroomer
Thegroomerbladeheight/depthcanbesetusingthe
followingchart,gures,andprocedure:
Numberofrear-rollerspacers
required
Heightofcut(HOC)Groomer-armpositionHeightofgroomingrange
(HOG)
0
1.5mm(0.06inch)
3.0mm(0.12inch)
4.8mm(0.19inch)
6.4mm(0.25inch)
A
A
B
B
0.8to1.5mm(0.03to0.06inch)
1.5to3.0mm(0.06to0.12inch)
2.3to4.8mm(0.09to0.19inch)
3.0to6.4mm(0.12to0.25
inch)
1
7.9mm(0.31inch)
9.7mm(0.38inch)
B
B
3.8to7.9mm(0.15to0.31inch)
4.6to9.7mm(0.18to0.38
inch)
2
11.2mm(0.44inch)
12.7mm(0.50inch)
B
B
5.3to11.2mm
(0.21to0.44inch)
6.4to12.7mm(0.25to
0.50inch)
3
15.9mm(0.625inch)
B
9.4to12.7mm(0.37to0.50
inch)
4
19.1mm(0.75inch)
B
12.7to15.7mm(0.50to0.62
inch)
A
B
C
G027983
g027983
Figure19
1.A=Lowheight-of-groom
range
3.C=TransportforBrange
(reducesclearancetothe
grassbasket)
2.B=Highheight-of-groom
range/TransportforA
range
Note:IfyouareusingthegroomeronaneFlex
tractionunit,notethatthegroomercausestheunitto
drainthebatteryfasterthanwithout.Thedeeperyou
setthegroomer,themorepoweritwillrequireandthe
fasterthebatterychargewillbedepleted.
1.Makesurethattherollersareclean.Position
themachineonaat,levelworksurface.
2.Usingtheabovechart,determinetheamountof
rearrollerspacersrequiredtoattainthedesired
groomingheight/depth.
Note:Ifinstalling3or4spacersoneachsideof
therearroller,usethelongerscrews(included
inlooseparts)insteadofthestandardscrews.
3.Settheheightofcutofthemainreel.
4.Usingthechart,determinethepositionrequired
toattainthedesiredgroomingheight/depth.
Raiseorlowerthegroomingreelasfollows:
A.Loosentheboltsontherightandleft
groomerarms(Figure20).
10
