Toro 04260 - Replacing the Grooming Reel

ReplacingtheGrooming
Reel
Youcanremovethegroomingreeltoreplace
individualbladesortheentireshaft.Removeand
replacethegroomingreelshaftusingthefollowing
procedure:
1.Removethegearboxcoverfromthegroomer
housing(Figure26).
G018184
1
2
3
g018184
Figure26
1.Bolt
2.Gearboxcover
3.Gasket
2.Loosentheboltsecuringtherollershafttothe
height-of-cutarm(Figure27).
g030197
Figure27
1.Roller
2.Roller-shaftbolt
3.RemovethelocknutandBellevillewasher
securingtheheight-of-cutarmassemblyrodend
tothegroomerdriveassembly(Figure28).
g010439
Figure28
1.Rodendofheightofcut
assembly
3.Locknut
2.Bellevillewasher
4.Removetheplowbolt,nut,andwashersecuring
theheight-of-cutarmassemblytothesideplate
(Figure29).
1
2
G018182
g018182
Figure29
1.Adjuster-armassembly
2.Washerandheight-of-cut
nut
14
