g032705
Figure7
1.Electrolyte
4.Allowapproximately20to30minutesforthe
electrolytetosoakintotheplates.Fillas
necessarytobringtheelectrolytetowithinabout
6mm(1/4inch)ofthebottomofthellwell
(Figure7).
5.Connecta2to4Abatterychargertothebattery
posts.Chargethebatteryforatleast2hoursat
4Aorforatleast4hoursat2Auntilthespecic
gravityis1.250orhigherandthetemperatureis
atleast16°C(60°F)withallcellsgassingfreely.
WARNING
Chargingthebatteryproducesgasses
thatcanexplode.
Neversmokenearthebatteryandkeep
sparksandamesawayfromthebattery.
Important:Ifyoudonotchargethebattery
foratleastthetimespeciedabove,youmay
reducethelifeofthebattery.
6.Whenthebatteryischarged,disconnectthe
chargerfromtheelectricaloutletandbattery
posts.
Note:Afterthebatteryhasbeenactivated,
addonlydistilledwatertoreplacenormalloss,
althoughmaintenance-freebatteriesshouldnot
requirewaterundernormaloperatingconditions.
Important:Failuretocorrectlyactivatethe
batterymayresultinbatterygassingand/or
prematurebatteryfailure.
7.Installtheventcaps.
8.Placethebatteryonthebatterytrayandsecure
itwiththebatteryclampandfastenersremoved
previously.
9.Installthepositivecable(red)tothepositive(+)
terminalandthenthenegativecable(black)
tothenegative(–)terminalofthebatteryand
securethemwiththeboltsandnuts(Figure8).
Slidetherubberbootoverthepositiveterminal
topreventapossibleshortfromoccurring.
WARNING
Incorrectbatterycableroutingcoulddamage
thetractorandcables,causingsparks.
Sparkscancausethebatterygassesto
explode,resultinginpersonalinjury.
•Alwaysdisconnectthenegative(black)
batterycablebeforedisconnectingthe
positive(red)cable.
•Alwaysconnectthepositive(red)battery
cablebeforeconnectingthenegative
(black)cable.
g005098
Figure8
1.Negative(-)
2.Positive(+)
5
InstallingtheOilCooler
Optional
Partsneededforthisprocedure:
–
OilCoolerKit—Greensmaster3300SeriesTraction
Unit(PartNo.119-1691[purchasedseparately])
Procedure
Ifyouareoperatingthemachineinhotclimates,
wheretheambienttemperatureisabove29°C(85°F),
orusingitforheavy-dutyuse(mowingotherthan
greens,suchasfairwaysorverticutting),installthe
optionalhydraulicoilcoolerkit(PartNo.119-1691).
13
