Fuel-ShutoffValve
Closethefuel-shutoffvalve(Figure22),behind
theseatandunderthefueltank,whenstoringor
transportingthemachineonatruckortrailer.
g014626
Figure22
1.Fuelshutoff(underthefueltank)
CuttingUnitPowerDisconnect
Connectors
Beforeinstalling,removing,orworkingonthecutting
units,disconnectthecuttingunitsfromthepower
supplybyseparatingthecuttingunitpowerdisconnect
connectors(Figure23),locatedatthebaseofthe
rolloverbarontheleftsideofthetractionunit.Plug
theconnectorstogetherbeforeoperatingthemachine.
g016588
Figure23
1.Cuttingunitpowerdisconnectconnector
CAUTION
Ifyoudonotdisconnectthepowertothe
cuttingunits,someonecouldaccidentally
startthecuttingunit,causingseriousinjury
tohandsandfeet.
Alwaysseparatethecuttingunitpower
disconnectconnectorsbeforeworkingonthe
cuttingunits.
Specications
Note:Specicationsanddesignaresubjectto
changewithoutnotice.
Widthofcut151cm(59.5inches)
Wheeltread
128cm(50.5inches)
Wheelbase
119cm(46.9inches)
Overalllength(w/baskets)249cm(98.0inches)
Overallwidth179cm(70.6inches)
Overallheight205cm(80.8inches)
Weight
Refertothemachineserial
tag(Figure1).
