InstallingtheGrass-Basket
Hooks
Partsneededforthisprocedure:
6
Grass-baskethook
12Flangebolts
Procedure
Installthe6grass-baskethooksontotheendsofthe
suspension-armbarsusingthe12angebolts(Figure
9).
g015492
Figure9
1.Flangebolt
3.Suspension-armbar
2.Grass-baskethook
7
InstallingtheCuttingUnits
Partsneededforthisprocedure:
1
Gaugebar
3
Cuttingunit(obtainfromyourauthorizedT oro
distributor)
3
Grassbasket
3Electric-reel-motorcounterweight
6
Capscrew
3
O-ring
Procedure
1.Preparethecuttingunitsforinstallation;referto
yourcuttingunitOperator’sManual.
2.Applygreasetotheinsidediameterofthedrive
coupler.
3.InstallanO-ringtoeachreelmotorasshown
inFigure10.
g256064
Figure10
4.Installtheelectric-reel-motorcounterweight;
refertoInstallingtheElectricalCounterweights
(page47).
5.Installthecuttingunits;refertoInstallingthe
CuttingUnits(page47).
