Toro 08761 Service Manual

AdjustingtheTractionSystemforNeutral
ThetractionpedalmustreturntotheNEUTRALpositionwhenreleasedfromeither
theforwardorreverseposition.Themachinemustnotcreepineitherdirection
onlevelgroundwheninthetractionpedalisintheNEUTRALposition.Adjustthe
tractionsystemforneutralasfollows:
1.Parkthemachineonalevelsurface,loweranyattachmentsandsetthekey
switchtotheOFFposition.
2.Removethecentershroud.
WARNING
ReviewandfollowtheJackingInstructions(page1–6)beforelifting
themachine.
3.Raiseallofthewheelsoffthegroundandsupportthemachinewithjack
stands.
4.Loosenthelocknutonthetraction(piston)pumpadjustmentcam.
g350623
Figure46
1.Locknut3.Tractionneutralswitch
2.Tractionadjustmentcam
5.HaveanassistantsitintheOperator’sseat,starttheengine,andsetthe
throttletohighidle.
6.UsethelargehexontheadjustthecamtoadjusttheNEUTRALposition:
A.Turntheadjustmentcamslowlyuntilthewheelbeginstorotateinthe
forwarddirection(positionF).
HydraulicSystem:Adjustments
Page5–52
SandPro
®
3040and5040
20251SLRevA
