Toro 08761 Service Manual

JackingInstructions
DANGER
Mechanicalorhydraulicjacksmayfailtosupportthemachineand
causeaseriousinjury.
•Usejackstandstosupporttheraisedmachine.
•Useonlymechanicalorhydraulicjackstoliftthemachine.
•Donotusetheattachmentorimplementasajackingpoint.
1.Parkthemachineonalevelsurface,lowerorremoveanyattachments,
engagetheparkingbrake,setthekeyswitchtotheOFFpositionandremove
thekeyfromthekeyswitch.
2.Positionthejacksecurelyunderthedesiredjackpoint:
•Front
IMPORTANT
Topreventdamagetooilcooler,ensurethatjackorjackstand
ispositioneddirectlyunderframe.
Positionthejacksecurelyundertheframetubejustbehindthefront
wheel.
•Rear
Positionthejacksecurelyundertherearwheelmotor.
Afterraisingthemachine,useanappropriatejackstandunderthemachine
frametosupportthemachine.
g340625
Figure1
1.Jackpoint–front
3.Jackpoint–rear
2.Jackstandpoint–front
4.Jackstandpoint–rear
Safety:JackingInstructions
Page1–6
SandPro
®
3040and5040
20251SLRevA
