Toro 08761 Service Manual

TableofContents
Preface................................................................................................................5
Chapter1:Safety............................................................................................1–1
SafetyInstructions.......................................................................................1–2
JackingInstructions.....................................................................................1–6
SafetyandInstructionalDecals....................................................................1–7
Chapter2:SpecicationsandMaintenance....................................................2–1
Specications...............................................................................................2–2
TorqueSpecications...................................................................................2–5
ShopSupplies............................................................................................2–12
SpecialT ools..............................................................................................2–14
Chapter3:Troubleshooting.............................................................................3–1
GEARS–TheSystematicApproachtoDening,DiagnosingandSolving
Problems......................................................................................................3–2
Troubleshooting–Hydraulic.........................................................................3–3
GeneralHydraulicSystemProblems............................................................3–4
TractionSystemProblems............................................................................3–6
SteeringSystemProblems(Model08745Only)............................................3–8
AttachmentLift/LowerProblems...................................................................3–9
AttachmentHydraulicProblems..................................................................3–10
Troubleshooting–Electrical........................................................................3–11
StartingProblems.......................................................................................3–12
GeneralRunProblems...............................................................................3–14
AttachmentElectricalProblems..................................................................3–15
Chapter4:Engine...........................................................................................4–1
GeneralInformation.....................................................................................4–2
Adjustments.................................................................................................4–4
ServiceandRepairs.....................................................................................4–7
Chapter5:HydraulicSystem...........................................................................5–1
GeneralInformation.....................................................................................5–3
HydraulicSchematics.................................................................................5–12
HydraulicFlowDiagrams............................................................................5–13
TestingtheHydraulicSystem......................................................................5–23
Adjustments...............................................................................................5–51
ServiceandRepairs...................................................................................5–54
Chapter6:ElectricalSystem...........................................................................6–1
GeneralInformation.....................................................................................6–2
ElectricalSchematicsandWireHarnessDrawings/Diagrams.......................6–3
ElectricalSystemQuickChecks....................................................................6–4
TestingtheElectricalComponents................................................................6–6
ServiceandRepairs...................................................................................6–28
Chapter7:Chassis..........................................................................................7–1
GeneralInformation.....................................................................................7–2
ServiceandRepairs.....................................................................................7–3
AppendixA......................................................................................................A–1
ElectricalDrawingDesignations....................................................................A–2
HydraulicSchematic–SandPro3040..........................................................A–3
HydraulicSchematic–SandPro5040..........................................................A–4
ElectricalSchematic–SandPro3040/5040..................................................A–5
WireHarnessDrawing–SandPro3040/5040..............................................A–6
WireHarnessDiagram–SandPro3040/5040..............................................A–7
WireHarness–RearRemoteHydraulics(Optional)......................................A–8
WireHarness–SwitchKit(Optional)............................................................A–9
AdditionalReferenceMaterials
Briggs&StrattonV-TwinEngineServiceManual
SandPro
®
3040and5040
Page7
Preface
20251SLRevA
