ProductOverview
Controls
Handle
Usethehandletoraiseandlowertheedger(Figure10).
Figure10
1.Handle
AlignmentGuide
Loosentheadjustmentscrewandmovethealignmentguide
tothedesiredposition(Figure11).
Figure11
1.Adjustmentscrew2.Alignmentguide
Operation
Note:Determinetheleftandrightsidesofthemachine
fromthenormaloperatingposition.
OperatingtheEdger
1.Starttheengine.
2.Pressoutwardonthehandleandlowertheedgerblade
totheground(Figure10).
3.EngagethebladebypullingupontheRemote
Hydraulicscontrolknob(Figure12).
Figure12
1.Remotehydraulicscontrolknob
4.Slowlymoveforward,nottravelingfasterthan1to2
mph.
5.Tostoptheedgingoperation:
•Pressoutwardonthehandleandraisetheedger
bladetothetransportposition(Figure10).
•Disengagethebladebypushingdownonthe
RemoteHydraulicscontrolknob(Figure12).
AdjustingtheEdgerBlade
Depth
1.MovethethrottlecontroltotheSlowpositionand
rotatetheignitionkeytoOffandremovethekeyfrom
theswitchtopreventaccidentalstarting.
2.Raisetheedgertothetransportposition.
3.Removethescraperrodfromtherollershaft(Figure
13).
