Setup
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
ProcedureDescription
Qty.
Use
Crosstubeassembly
1
Screw(3/8x3inch)
4
Flatwasher4
1
Locknut(3/8inch)
4
Mountthecrosstubeassembly.
Cutterheadassembly
1
2
Hitchpin1
Installthecutterheadassembly.
Hoseguide1
3
Flangenut1
Installthehoseguide.
4
Nopartsrequired
–
Routethehydraulichoses.
5
Nopartsrequired
–
Checkthehydraulicuid.
MediaandAdditionalParts
Description
Qty.
Use
Partscatalog1
Usetoreferencepartnumbers
Operator'sManual
1
Readbeforeoperatingthemachine
Certicateofconformity
1
Declarationofconformity
Note:Determinetheleftandrightsidesofthemachine
fromthenormaloperatingposition.
Note:TooperatetheSportsFieldEdger,thetractionunit
mustbeequippedwiththeRearRemoteHydraulicsKit,
Model08781.IftheserialnumberoftheRearRemote
HydraulicsKitispriorto310000001,youmustupdatethe
RearRemoteHydraulics.ProceedtoStep1inSetup.
