Toro 08766 - Mounting the Cross Tube Assembly; Installing the Cutter Head Assembly

1
MountingtheCrossTube
Assembly
Partsneededforthisprocedure:
1
Crosstubeassembly
4
Screw(3/8x3inch)
4Flatwasher
4
Locknut(3/8inch)
Procedure
Note:IftheSandProisequippedwiththemid-mounttool
system,removethefastenerssecuringthesaddlebracketand
footguards(ifsoequipped)toeachsideofthemachine.
Removeanddiscardthesaddlebrackets,footguardsand
fasteners(Figure3).Supportthemid-mounttoolsystemto
preventitfromlowering.
Figure3
1.Saddlebracket
2.Footguard
1.Fromtheleftsideofthemachine,slidethecrosstube
assemblyunderthemachine,aligningthemounting
bracketholeswiththeholesineachframetube(Figure
4).
Figure4
1.Crosstubeassembly
2.Securethecrosstubemountingbracketstotheframe
tubeswith4screws(3/8x3inch),atwashers,and
locknuts(3/8inch)(Figure4).
2
InstallingtheCutterHead
Assembly
Partsneededforthisprocedure:
1
Cutterheadassembly
1Hitchpin
Procedure
1.Slidethecutterheadpivottubeontothecrosstube
(Figure5).
7
