Toro 20192 - Checking Engine Oil Level; Adjusting Cutting Height; Adjusting Upper Handle Height

CheckingtheEngineOilLevel
ServiceInterval:Beforeeachuseordaily
1.Removethedipstick,wipeitclean,andinsertitinto
theoilllerneck,butdonotscrewitin(Figure13).
Figure13
2.Removethedipstickandchecktheoillevel
(Figure13).
Ifthereisnooilonthedipstick,slowlypouroil
intotheoillltube,periodicallycheckingthelevel
withthedipstick,untilthedipstickindicatesthat
theengineisfullasillustratedinFigure13.Donot
overll.(Max.ll:0.58quart(0.55l),type:SAE
30detergentoilwithanAPIserviceclassication
ofSH,SJ,SL,orhigher.)
Note:Ifyouoverlltheengine,poursomeoilout
ofitasdirectedinChangingtheEngineOil.
3.Installthedipsticksecurely.
AdjustingtheCuttingHeight
Adjustingthecuttingheightmaybringyouinto
contactwiththemovingblade,causingserious
injury.
•Stoptheengineandwaitforallmovingparts
tostop.
•Donotputyourngersunderthehousing
whenadjustingthecuttingheight.
Adjustthecuttingheightasdesired.Setallfourwheels
tothesameheight.
Note:Toraisethemower,moveall4cuttingheight
leversforward;tolowerthemower,movethem
rearward.
Figure14
AdjustingtheUpperHandle
Height
Youmayraiseorlowertheupperhandletoaposition
comfortableforyou.
Note:Youcannotraisetheupperhandlehigherthan
theangleofthelowerhandle.
1.Loosentheupperhandleknob(Figure15).
