5.Afterattainingthedesiredwheelalignment,

assembleballjointtothemountingbracketwith

thecastlenutandcotterpin.

6.Tightenthelocknutandboltatthetie-rodclamp.

TorquingtheBoltsforthe

Steering-CylinderMount

4-WheelDriveMachinesOnly

ServiceInterval:Every200hours

1.Movethemachinetoalevelsurface,shutoffthe

engineandremovethekeyfromthekeyswitch.

2.Torquethe4boltsforthesteering-cylinder

mount(Figure64)to65to81N∙m(48to60ft-lb).

g003496

Figure64

1.Bolt—4each(steering-cylinder-mount)

AdjustingtheTraction

Drive

Ifthemachinemoveswhenthetractionpedalisinthe

neutralposition,adjustthetractioncam.

PreparingtoAdjusttheTraction

Drive

Liftingequipmentandjackstandcapacity:1900

kg(2ton)orgreater

1.Movethemachinetoalevelsurface,shutoffthe

engine,andengagetheparkingbrake.

WARNING

Ifthemachineisnotsupported

adequately,itmayaccidentallyfall,

injuringanyoneunderthemachine.

Raiseall4wheelsoffthegroundorthe

machinemaymovewhileadjustingthe

tractiondriveforneutral.

2.Raisethemachineandsupportitwith4jack

standsofthespeciedcapacityundertheframe.

3.Removetheseatandseatplate;referto

RemovingtheSeatandSeatPlate(page39).
