ProductOverview
Specications
Note:Specicationsanddesignaresubjecttochange
withoutnotice.
Widthof
Cut
62inches(1.575m)or72inches(1.829m)
Height
ofCut
Adjustablefrom1to5inches(25to127mm)in1/2
inch(13mm)increments
Net
Weight
Model30403–420lbs.(190kg)
Model30404–510lbs.(510kg)
Attachments/Accessories
AselectionofToroapprovedattachmentsand
accessoriesareavailableforusewiththemachineto
enhanceandexpanditscapabilities.Contactyour
AuthorizedServiceDealerorDistributororgoto
www.Toro.comforalistofallapprovedattachments
andaccessories.
Operation
Note:Determinetheleftandrightsidesofthe
machinefromthenormaloperatingposition.
CAUTION
Ifyouleavethekeyintheignitionswitch,someone
couldaccidentlystarttheengineandseriously
injureyouorotherbystanders.
Removethekeyfromtheignitionbeforeyoudo
anymaintenance.
CheckingtheLubricantinthe
GearBox
ThegearboxindesignedtooperateonSAE80–90
wt.gearlube.Althoughthegearboxisshippedwith
lubricantfromthefactory,checkthelevelbefore
operatingthecuttingunit.
1.Positionthemachineandcuttingunitonalevel
surface.
2.Removethedipstick/llplugfromthetopof
thegearbox(Figure6)andmakesurethatthe
lubricantisbetweenthemarksonthedipstick.If
thelubricantlevelislow,addenoughlubricantuntil
thelevelisbetweenthemarks.
Figure6
1.Dipstick/llplug
AdjustingtheHeight-of-Cut
Theheight-of-cutisadjustablefrom1to5inches(25
to127mm)in1/2inch(13mm)increments.Toadjust
theheight-of-cut,positionthecastorwheelaxlesinthe
upperorlowerholesofthecastorforks,addorremove
anequalnumberofspacersfromthecastorforksand
