Toro 30716 - Installing the Lift Chains; Greasing the Machine; Installing Rear Weight

6
InstallingtheLiftChains
NoPartsRequired
Procedure
1.Connecttheliftchainstotheliftarmandcuttingunit
chainbracketswith6shackles,shacklepins(3/8x
1-1/2inches),andcotterpins(1/8x3/4inch)(Figure
9).Toensurethatthecuttingunitliftsproperly,secure
thechainstothefollowinglinkswhenconnecting:
•Frontchains-9thlink
•Rearchain-5thlink
2.Checktheoperationtoensurethatthechainsliftthe
decktightagainstthestopswhentheliftarmisraised.
Figure9
1.Frontleftliftchain3.Rearliftchain
2.Frontrightliftchain
7
GreasingtheMachine
NoPartsRequired
Procedure
Beforeoperatingthemachine,itmustbegreasedtoensure
properlubricatingcharacteristics;refertoGreasingthe
BearingsandBushings.Failuretoproperlygreasethemachine
willresultinprematurefailureofcriticalparts.
8
InstallingRearWeight
NoPartsRequired
Procedure
TwoWheelDriveGroundsmaster300SeriesTractionUnits
complywiththeANSIB71.4-2004andEN836Standards
whenequippedwithrearweight.RefertochartinTraction
UnitOperator'sManualtodeterminethecombinationsof
weightrequired.OrderpartsfromyourlocalAuthorized
ToroDistributor.
FourWheelDriveGroundsmaster300SeriesTractionUnits
donotneedadditionalrearweighttocomplywiththeANSI
B71.4-2004andEN836Standards.
12
