ProductOverview
Specications
Note:Specicationsanddesignaresubjecttochange
withoutnotice.
Widthof
Cut
1.829m(72inches)
Height
ofCut
Adjustablefrom38to114mm(1–1/2to4–1/2inches)
in1/2inch(13mm)increments
Net
Weight
275kg(607lb.)
Attachments/Accessories
AselectionofToroapprovedattachmentsandaccessoriesis
availableforusewiththemachinetoenhanceandexpand
itscapabilities.ContactyourAuthorizedServiceDealeror
Distributororgotowww .Toro.comforalistofallapproved
attachmentsandaccessories.
Operation
Note:Determinetheleftandrightsidesofthemachine
fromthenormaloperatingposition.
CAUTION
Ifyouleavethekeyintheignitionswitch,someone
couldaccidentlystarttheengineandseriously
injureyouorotherbystanders.
Removethekeyfromtheignitionbeforeyoudoany
maintenance.
CheckingtheLubricantinthe
GearBox
ServiceInterval:Every50hours
ThegearboxindesignedtooperateonSAE80–90wt.gear
lube.Althoughthegearboxisshippedwithlubricantfrom
thefactory,checkthelevelbeforeoperatingthecuttingunit.
1.Positionthemachineandcuttingunitonalevelsurface.
2.Removethedipstick/llplugfromthetopofthegear
box(
Figure10)andmakesurethatthelubricantis
betweenthemarksonthedipstick.Ifthelubricant
levelislow ,addenoughlubricantuntilthelevelis
betweenthemarks.
Figure10
1.Dipstick/llplug
AdjustingtheHeight-of-Cut
Theheightofcutisadjustablefrom38to114mm(1-1/2
to4-1/2inches)in1/2inch(13mm)increments,byadding
orremovinganequalnumberofspacersfromthefrontand
rearcastorforks.Theheight-of-cutchartbelowgivesthe
combinationsofspacerstouseforallheight-of-cutsettings.
13
