5.Aligntheholesinthenestedendsoftherodsand
insert2carriagebolts(intheloosepartsbag)through
theshortrodfromtheleftsideofthemachine(from
theoperatingposition).
6.Insertthecableclipthatsupportsthedeectorcable
ontotheforwardcarriagebolt,andsecurethecarriage
boltswithlocknutsfromtheloosepartsbag(Figure
11).
Figure11
1.Cableclip2.Deectorcable
7.HoldthebluetriggercapdownandrotatetheQuick
Stickinacircletoensurethatthechuteanddeector
operatesmoothly.
5
FillingtheEnginewithOil
NoPartsRequired
Procedure
Yourmachinecomeswithoilintheenginecrankcase.
Note:Beforestartingtheengine,checktheoilleveland
addoilifnecessary.
UseautomotivedetergentoilwithanAPIserviceclassication
ofSF,SG,SH,SJ,SL,orhigher.Refertoyourengineowner's
manual.
Use
Figure12belowtoselectthebestoilviscosityforthe
outdoortemperaturerangeexpected:
g019049
Figure12
EngineOilCapacities
Model
EngineOilCapacity
38816
0.53to0.59l(18to20oz.)
1.Removethedipstickandslowlypouroilintothe
oillltubetoraisetheoilleveltotheFullmarkon
thedipstick.Donotoverll(Figure13).Referto
CheckingtheEngineOilLevelinMaintenance.
g018886
Figure13
2.Installthedipsticksecurely.
Note:Donotspilloilaroundtheoillltube;oilcould
leakontotractionpartsandcausethetractiontoslip.
11
